The Rotary Screw Air Compressor
The rotary screw air compressor produces an
ongoing movement to generate power.For certain heavy-duty industrial
operations, or a facility that needs to keep running their compressor 24/7 365
days a year, a piston compressor is considered insufficient. In order to get
the pressure intensity needed for complex pneumatic and other high-powered
tools, you will need to consider buying a rotary screw air compressor.
In a rotary screw
compressor, air is compressed with a meshing pair of rotors. As the screws move
in rotation, fluids gets sucked in, compressed and ejected.
 |
| COMPRESSOR REPAIR NEAR ME |
So, how does an oil injected rotary screw
compressor work?
AIR
The outside air is
sucked in by the screw element (air-end) through the air inlet filter. The
inlet filter makes sure that all the dust and dirt stays outside.
Load and unload control
Before the air enters
the screw element, it passed the inlet valve or unloader valve. This valve
opens and closes the air supply to the screw element.
When it’s open, the compressor is in ‘loaded’ condition:
When the valve is closed,
is shuts off the air supply to the compressor element: the motor and screw
element are turning, but the compressor is not sucking any air in and is not
pumping any air to the system.
 |
| COMPRESSOR REPAIR NEAR ME |
WHAT DOES THE screw
compressor element DO?
When the inlet/unloader
valve is open, the air enters the compressor screw element.
The screw element works
like a pump and it compressed the air. During this process, oil is injected in
the element. The oil is there to cool the air, as the air gets very hot during
compression.
Compressed air/oil mixture
This mixture leaves the
screw element through a one-way valve. This valve makes sure that the oil
cannot flow back into the compressor element through the exit pipe.
WHAT IS THE PURPOSE OF THE OIL SEPARATOR?
It's job is to basically
separate the oil and the air through the separator tank. Most of the oil is
separated from the compressed air by centrifugal force . The remaining oil is
separated by the separator element which looks exactly like a big filter.
The air with oil flows through the separator element and separates the oil from
the compressed air. The separated oil is collected at the bottom of the
separator and is removed by the scavenge line. It sucks the collected oil back
to the compressor element.
 |
| COMPRESSOR REPAIR NEAR ME |
WHAT IS THE MINIMUM PRESSURE VALVE?
The minimum pressure valve is a spring-loaded valve that opens at a certain pressure, about 2.5 bar. The minimum pressure valve makes sure that there is always a minimum pressure inside the compressor
The after cooler
The compressed air is
still very hot, consequently the compressed air is now cooled by the after
cooler before it leaves the compressor. The air temperature after the cooler is
around 25 – 40 degrees Celsius.
Because of the cooling
down of the air, a lot of water vapor has condensed against the inside of the
after cooler. This water is carried with the compressed air towards the air
outlet of the compressor.
Moisture trap
The condenstate trap
(moisture trap) basically separates the water from the compressed air. The
water is drained through a small hose.
Oil flow
The oil is cooled by the
oil cooler. The amount of cooling is controlled by a thermostatic valve. If the
oil is still cold, the oil cooler is completely by-passed. If the oil is very
hot, all the oil is led through the oil cooler.
The Oil filter
Finally, the oil flows
through the oil filter. The oil filters removes all the dirt and dust that has
collected in the oil.
Air Compressor Sales, Repairs, and Services
When air compressors at
your facility begin to malfunction, you’re likely to encounter a lot of
problems. Faulty machines can halt your operations and cost you thousands of
dollars in lost productivity and labor. Prevent future complications when you
turn to H&K Pump in Dallas, Texas! We fix air compressors and
pumps for all brands on the market today.
Services and Parts
Our company services all
air compressors of all brands. We diagnose and resolve any problem right away
for your convenience. Our team is also experienced in preventive maintenance
services.
Some of our clients
include companies in the aerospace, mining, and forestry industries, as well as
the following:
- Food Manufacturers
- Industrial Plants
- Automotive Facilities
- Paint and Body Shops
- Machine Shops
- Metal Manufacturers
- Dry Cleaners
- Food Factories
- Paper Mills
- 18-Wheelers
 |
| AIR COMPRESSOR REPAIR NEAR ME |
 |
| AIR COMPRESSOR SERVICE NEAR ME |
 |
| COMPRESSOR SERVICE NEAR ME |
 |
| COMPRESSOR REPAIR NEAR ME WWW.HKAIRCOMPRESSORS.COM |
|
MODEL |
HP |
VOLT |
PSI |
CFM |
PART # |
|
NxB08 |
10 |
230 |
FNB08BXX3HXXX |
||
|
NxB08 |
10 |
460 |
100 |
45 |
FNB08BXX4HXXX |
|
NxB08 |
10 |
230 |
FNB08BXX3JXXX |
||
|
NxB08 |
10 |
460 |
125 |
42 |
FNB08BXX4JXXX |
|
NxB08 |
10 |
230 |
FNB08BXX3KXXX |
||
|
NxB08 |
10 |
460 |
150 |
37 |
FNB08BXX4KXXX |
|
NxB08 |
10 |
230 |
FNB08BXX3LXXX |
||
|
NxB08 |
10 |
460 |
175 |
33 |
FNB08BXX4LXXX |
|
NxB11 |
15 |
230 |
FNB11BXX3HXXX |
||
|
NxB11 |
15 |
460 |
100 |
63 |
FNB11BXX4HXXX |
|
NxB11 |
15 |
230 |
FNB11BXX3JXXX |
||
|
NxB11 |
15 |
460 |
125 |
58 |
FNB11BXX4JXXX |
|
NxB11 |
15 |
230 |
FNB11BXX3KXXX |
||
|
NxB11 |
15 |
460 |
150 |
50 |
FNB11BXX4KXXX |
|
NxB11 |
15 |
230 |
FNB11BXX3LXXX |
||
|
NxB11 |
15 |
460 |
175 |
45 |
FNB11BXX4LXXX |
|
NxB15 |
20 |
230 |
FNB15BXX3HXXX |
||
|
NxB15 |
20 |
460 |
100 |
82 |
FNB15BXX4HXXX |
|
NxB15 |
20 |
230 |
FNB15BXX3JXXX |
||
|
NxB15 |
20 |
460 |
125 |
77 |
FNB15BXX4JXXX |
|
NxB15 |
20 |
230 |
FNB15BXX3KXXX |
||
|
NxB15 |
20 |
460 |
150 |
72 |
FNB15BXX4KXXX |
|
NxB15 |
20 |
230 |
FNB15BXX3LXXX |
||
|
NxB15 |
20 |
460 |
175 |
62 |
FNB15BXX4LXXX |
|
NxB08 |
10 |
230 |
FNB08BXD3HXXX |
||
|
NxB08 |
10 |
460 |
100 |
45 |
FNB08BXD4HXXX |
|
NxB08 |
10 |
230 |
FNB08BXD3JXXX |
||
|
NxB08 |
10 |
460 |
125 |
42 |
FNB08BXD4JXXX |
|
NxB08 |
10 |
230 |
FNB08BXD3KXXX |
||
|
NxB08 |
10 |
460 |
150 |
37 |
FNB08BXD4KXXX |
|
NxB08 |
10 |
230 |
FNB08BXD3LXXX |
||
|
NxB08 |
10 |
460 |
175 |
33 |
FNB08BXD4LXXX |
|
NxB11 |
15 |
230 |
FNB11BXD3HXXX |
||
|
NxB11 |
15 |
460 |
100 |
63 |
FNB11BXD4HXXX |
|
NxB11 |
15 |
230 |
FNB11BXD3JXXX |
||
|
NxB11 |
15 |
460 |
125 |
58 |
FNB11BXD4JXXX |
|
NxB11 |
15 |
230 |
FNB11BXD3KXXX |
||
|
NxB11 |
15 |
460 |
150 |
50 |
FNB11BXD4KXXX |
|
NxB11 |
15 |
230 |
FNB11BXD3LXXX |
||
|
NxB11 |
15 |
460 |
175 |
45 |
FNB11BXD4LXXX |
|
NxB15 |
20 |
230 |
FNB15BXD3HXXX |
||
|
NxB15 |
20 |
460 |
100 |
82 |
FNB15BXD4HXXX |
|
NxB15 |
20 |
230 |
FNB15BXD3JXXX |
||
|
NxB15 |
20 |
460 |
125 |
77 |
FNB15BXD4JXXX |
|
NxB15 |
20 |
230 |
FNB15BXD3KXXX |
||
|
NxB15 |
20 |
460 |
150 |
72 |
FNB15BXD4KXXX |
|
NxB15 |
20 |
230 |
FNB15BXD3LXXX |
||
|
NxB15 |
20 |
460 |
175 |
62 |
FNB15BXD4LXXX |
